Digimon Console

Featuring an explosion-proof enclosure, the easy-to-use Digimon Console can be installed anywhere on a fuel site, including hazardous areas. The Digimon Console offers streamlined inventory monitoring capabilities while providing the most amount of installation flexibility. Featuring an explosion-proof enclosure, the console can be installed in hazardous areas. This capability provides operators convenient access to essential inventory information during deliveries and tank maintenance.

Features and Benefits

Digimon Console Features and Benefits

Cost-Effective: Console is engineered to reduce installation expenses and to provide streamlined inventory data.

Install Anywhere: Explosion-proof and weatherproof console may be installed virtually anywhere on-site.

Easy To Set Up: Battery-powered console eliminates need to run power to console; software makes programming console easy.

Easy To Use: Operators can easily activate dormant console with a key to access essential inventory data.

Features

Circular, explosion-proof enclosure
Compatible with explosion-proof magnetostrictive probe
Event recording (up to 32 GB removable micro SD card)
Displays product height, water height, ullage and product temperature
Displays alarm signals and unit of measure
Tank comparison table and memorization in non-volatile memory of the 250 points mm/liters conversion table

Digimon 16 T ATEX

Displays inventory information for up to 16 tanks
Graphic color TFT 2.7” display
4 capacitive function keys for menu management

Digimon LCD ATEX

Displays inventory information for 1 tank
Back-lit alphanumeric display, 16 characters over 2 lines

Benefits

Console’s explosion-proof enclosure enables operators to get readings at the tank
Console available in 2 models for single- or multiple-tank sites
Can be connected to a SiteSentinel® Integra™ or SiteSentinel® Nano® tank gauge for expanded inventory data
Several standard communication protocols already integrated: Gilbarco, Tokheim, Dresser Wayne, Retalix, Orpak, DOMS compliance
Display stays dormant until activated by key to reduce power consumption
Configuration software makes programming console easy

Listings and Certifications

Digimon 16 T ATEX
INERIS 06ATEX0051 II 2 GD Ex d IIC T6 Ex tD A21
IP66/68 T85 °C Tamb: from -20 °C to 60 °C

Specifications

Digimon Console Technical Specifications

Digimon 16 T ATEX

IP68 protection (max. depth 1 m. for an hour)
One (1) RS-232 serial port
Two (2) RS-485 serial ports
Four (4) programmable relays 250 VAC 1A
Four (4) digital/analog inputs
Power: 9-30 VDC and internal battery with measure on request through a magnet

Digimon LCD ATEX

IP68 protection (max. depth 1 m. for an hour)
Two (2) RS-485 serial connections for Multipoint bus
One (1) RS-232 serial connection for data transmission and configuration
Four (4) NO/NC V 250 VAC 1A programmable relays
Power: 9-30 VDC and internal battery with measure on request through a magnet
